概述

GM500 Mini PCIe旨在为客户提供LTE连接的全球网络覆盖，支持50Mbps的上传和150Mbps的下载数据速率，还可以与现有的3G和2G网络完全向后兼容。

RX分集允许终端设备配备两个不同的蜂窝天线，从而提高无线连接的质量和可靠性。

该款产品支持丰富的互联网协议（用于PPP连接的PAP和CHAP）和丰富的功能（GNSS、远程唤醒、TCP/UDP、FTP、HTTP、SMS），可将模组的适用性扩展到广泛的M2M应用。

GM500 Mini PCIe可广泛应用于M2M行业，如智能电表、安防、工业路由器、DTU、CPE、Telematics等。

产品亮点

PCIe Form Factor

LTE Cat.4

Rx diversity

UART

LTE FDD&WCDMA&GSM

USB 2.0

Embedded TCP/UDP

Embedded FTP/HTTP

-40℃ ~ 85 ℃

Auto suspend

Remote wakeup

技术规格

General Features

* Pin-to-Pin with PCIE

* Dimensions: 51mm × 31mm× 4.75mm

* Weight: About 10.0g

* Frequency Band :

--LTE FDD/WCDMA/GSM

Electrical & Sensitivity

* Transmit Power:

--LTE: 23 ±2.7dBm (Power Class 3)

--WCDMA : 24 +1/-3dBm (Power Class 3)

--GSM900 : 33±2dBm (Power Class 4)

--GSM1800: 30±2dBm (Power Class 1)

* Receiving sensitivity:

--Rx Diversity

* Power Supply :

--3.4V -- 4.2V(3.8V is recommended)

Environmental

* Operation temperature: -30°C to +75°C

--Extreme Operating temperature: -40°C to +85°C

* Storage temperature: -40°C to +85°C

* Humidity: 5%~ 95%

RF Band

* U1G

1.LTE FDD: B2,B4,B5,B12,B13,B17,B25,B26

2.WCDMA:B2,B5

Data Features

* LTE FDD(Cat.4)

--Uplink 50Mbps / Downlink 150 Mbps

* WCDMA

--Uplink 5.76Mbps / Downlink 42Mbps

* GPRS (Multi-slot Class 10)

--Uplink 85.6 kbps / Downlink 85.6 kbps

Interfaces

* USB 2.0

* UART

* SIM interface (1.8/3.0V)

* Antenna (RF PAD for Primary, Diversity and GPS)

* LED indication

* Reset & Power-on

* WAKE-IN & WAKE-OUT

Applications

* Support embedded TCP & UDP protocols

* Support protocols PAP and CHAP used for PPP connection

* USB Selective Suspend & Remote wakeup

* RAS /ECM/NDIS

* Control Via AT Commands according to 3GPP TS27.005, 27.007 and Gosuncn RichLink extended AT commands

SMS Features

* Support Text and PDU mode

* Point to point MO and MT

* SMS Status Report

* SMS centre address setting

* Management of SMS

Driver & Tools

* Drivers

--Windows XP, Vista, 7 , 8, Win CE, Windows Mobile

--Linux

--Android

* Diag-log Tool

* Firmware Update Tool

认证

* FCC, GCF

* Verizon
