概述

GT117系列LTE有线跟踪器，内置Cat.1、Cat.M1和GSM模块、BLE、6轴传感器和独立GNSS芯片组。它提供多种外部接口，如RS232/RS485、1-wire、CAN BUS和其他I/O。它可以监测驾驶行为和牵引事件，并支持实时车辆跟踪。

GT117可以扩展到许多应用，如冷链物流、车队管理、运输管理等。

产品亮点

LTE Cat.1/Cat.M1/NB-IoT Optional Network

Support Multi-Constellation GNSS

2×HS-CAN, Double CAN channels for enhanced OEM PID Reading

Enhanced encryption algorithm

Remote trip tracking and vehicle state monitoring

eSIM optional

Built-in 3-axis G-sensor and 3-axis gyro

Support BLE accessories

技术规格

通用特性

- Dimension: 103.2×70.8×17.8mm

- Weight: About 100g(without harness)

硬件接口

- Power/GND: 2

- IGN: 1

- Digital Input: 3

- Analog Input: 1 0~32V

- Digital Output: 4 open drain with 150mA max driver current

- I/O: 1 can be configured as 0~32V analog input or an open drain with 150mA max driver current

- RS-485 ×1

- RS-232 ×1

- HS-CAN ×2

- 1-Wire Data ×1

- Out_5V: 1

- Antenna: Internal LTE/GNSS/BLE Antenna

- USB: 2.0 Type C

- LED: GNSS/Cell/Power

- SIM: 4FF or eSIM

网络连接

| North America Version

- LTE Cat.M1: B1, B2, B3, B4, B5, B8, B12, B13, B18,B19, B20, B25, B26, B27, B28, B66, B85

| EMEA Version

- LTE Cat.1: B1, B3, B7, B8, B20, B28

- GSM: B3, B8

| LATAM Version

- LTE Cat.1: B2, B3, B4, B5, B7, B8, B28, B66

- GSM: B2, B3, B5, B8

| Japan Version

- LTE Cat M1: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B85

- Cat.NB2: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B28, B66, B71, B85

- Bluetooth 5.2

发射功率

- LTE: Power class 5 for North America Version/Power class 3 for other Version

- GSM: Power class 4 for GSM850/900

- GSM: Power class 1 for GSM1800/1900

数据业务速率

- LTE Cat.1: Max 10Mbps(DL)/Max 5Mbps(UL)

- Cat.M1: Max 588Kbps(DL)/Max 1119Kbps(UL)

- Cat.NB2: Max 127Kbps(DL)/Max 158.5Kbps(UL)

- EDGE: Max 236.8Kbps(DL)/Max 236.8Kbps(UL)

- GPRS: Max 85.6Kbps(DL)/Max 85.6Kbps(UL)

GNSS

- GNSS: GPS, GLONASS, Galileo, BeiDou, SBAS and QZSS

- Sensitivity: -167dBm Tracking

- Accuracy: 1.5m CEP

- Hot start: <1s

- Cold start: <28s

供电

- Voltage: 8~32V

- Battery Capacity: 220mAh(Li-ion)

蓝牙

- Specification: 5.2

- Support peripherals: Ibutton,RFID Reader,Relay,TPMS, Temperature and Humidity sensor, BLE Tag

工作温度

- Operating Temp: -20℃ ~ 70℃

- Storage Temp: -40℃ ~ +85℃

- Humidity: 5%~95% RH

功能

- Location: GNSS/A-GPS(option)/LBS

- Time synchronization: GNSS/NTP

- Sensors: Built-in 3-axis G-sensor and 3-axis gyro. Used for motion detection, crash detection

- CAN: 2 HS-CAN channels. Used for vehicle data collection

- Ignition detection: ACC/GNSS/Main power ADC/Engine RPM

- Sleep mode: Automatically enter sleep mode when IGN off

- Configuration: Cloud/Cable/BLE

- FW update: FOTA/Cable

认证

- FCC, CE, RoHS, ANTEL*, JATE*, Telec*
